PAN PL3M2S-D4Y MkrTie,Wrap,Std,7.4i
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$2,464.63/m (1000 ea)
Usually ships within 6 to 10 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Panduit
Mfg Catalog # PL3M2S-D4Y
North Coast Part # 664954

Specifications

  • UNSPSC: 39121703
  • Product Segment: IEI
  • Product Type: Cable Tie
  • Sub Brand: Pan-Ty®
  • Note: PL3M2S-D4Y replaces PL3M2S-D4
  • Color: Yellow
  • Environment: Indoor
  • For Use With: Bundles
  • Marker Type: Wrap
  • Material: Nylon 6.6
  • Maximum Bundle Diameter (In.): 1.75
  • Maximum Bundle Diameter (mm): 45
  • Maximum Installation Temperature (°F): 32
  • Maximum Operating Temperature (°F): 185
  • Maximum Operating Temperature (°C): 85
  • Minimum Bundle Diameter (mm): 9.5
  • Minimum Bundle Diameter (In.): 0.37
  • Minimum Loop Tensile Strength (N): 222
  • Minimum Loop Tensile Strength (lb): 50
  • Minimum Operating Temperature (°F): -70
  • Minimum Operating Temperature (°C): -60
  • Overall Length (In.): 7.4
  • Overall Length (mm): 188
  • Body Width (mm): 4.7
  • Body Width (In.): 0.185
  • Body Thickness (mm): 1.3
  • Body Thickness (In.): 0.052
  • Resistance Properties: NA
  • Military Cross Reference Number: MS3368-4-4D
  • Standards Met: CE Compliant,RoHS Compliant
  • Application: General

Packaging Details

  • UPC: 07498344712
  • GTIN Package: 00074983447121
  • Standard Package Volume Ft3: 0.4966
  • Standard Package Weight Pounds: 5.4900
  • Std Package Height In: 3.5
  • Std Package Height MM: 88.9
  • Std Package Length In: 21
  • Std Package Length MM: 533.4
  • Std Package Width In: 12
  • Std Package Width MM: 304.8
  • Std. Pkg. UOM: Piece
  • UOM EA PK: PK
  • Std. Pkg. Qty.: 500
  • GTIN Carton: 50074983447126
  • Standard Carton Volume Ft3: 0.4966
  • Standard Carton Weight Pounds: 27.4500
  • Std Carton Height In: 18.41
  • Std Carton Height MM: 467.614
  • Std Carton Length In: 22.96
  • Std Carton Length MM: 533.4
  • Std Carton Width In: 10.46
  • Std Carton Width MM: 265.684
  • Std Ctn Qty: 2500
  • Min. Order UOM: Piece
  • Country of Origin 2Digit: SG
  • RoHS Compliant: Compliant
  • EAN: 00074983447121
  • REACH Status: False
  • California Pro65 Cancer: No
  • Buy American Compliant: Y
  • ARRA Compliant: Y
  • Mercury Content Indicator: No
  • Lead Content Indicator: N
  • Restricted Use of Hazardous Substances: N
  • Hazardous Material Flag: N
  • Min Order Qty: 500
  • Pallet Quantity: 40,000
  • Pallet Volume: 39.725000
  • Pallet Weight: 439.2000

Overview

UPC 07498344712
Item Long Description Pan-Ty marker tie, wrap, standard cross section, 7.4 (188mm) length, 87 x 1.79 (22.1 x 45.5mm) marker write-on area, nylon 6.6, yellow.
GTiN 00074983447121
Width 4.7 mm
Color Yellow
Type Cable Tie
Thickness 1.3 mm
Material Nylon
Applications General
Country of Origin SG
Pkg Qty 500
Family Brand Name Panduit
Max Operating Temperature 185 degrees F
Overall Length 7.4 in
Min Operating Temperature -70 degrees F
Tensile Strength 222 lb
Bundle Diameter 45 mm
Sub Brand Pan-Ty
CA Prop65 Warning No
UNSPSC 39121703
