Manufacturer Panduit
Mfg Catalog # PLT1M-M76
North Coast Part # 601389

Specifications

  • Product Segment: IEI
  • Product Type: Cable Ties
  • Environment: Indoor/Outdoor
  • Sub Brand: Pan-Ty®
  • For Use With: GTS-E, GS2B-E, PTS, PPTS, STS2
  • Material: Tefzel
  • Resistance Properties: Chemical, Radiation, UV and High Heat Resistant
  • Maximum Bundle Diameter (In.): 0.87
  • Maximum Bundle Diameter (mm): 22
  • Maximum Installation Temperature (°F): 32
  • Maximum Operating Temperature (°C): 170
  • Maximum Operating Temperature (°F): 338
  • Minimum Bundle Diameter (mm): 3.3
  • Minimum Bundle Diameter (In.): 0.13
  • Minimum Installation Temperature (°F): -4
  • Minimum Installation Temperature (°C): -20
  • Minimum Loop Tensile Strength (lb): 18
  • Minimum Loop Tensile Strength (N): 80
  • Minimum Operating Temperature (°C): -60
  • Minimum Operating Temperature (°F): -76
  • Overall Length (In.): 4
  • Overall Length (mm): 102
  • Body Width (mm): 2.5
  • Body Width (In.): 0.098
  • Body Thickness (In.): 0.043
  • Body Thickness (mm): 1.1
  • Standards Met: UL Recognized (File #E56854, UL 62275 Compliant (Type 1, 11), RoHS Compliant

Packaging Details

  • UPC: 07498354143
  • GTIN Package: 00074983541430
  • Standard Package Volume Ft3: 0.0637
  • Standard Package Weight Pounds: 1.2511
  • Std Package Height In: 2.65
  • Std Package Height MM: 67.31
  • Std Package Length In: 10.2
  • Std Package Length MM: 259.08
  • Std Package Width In: 6.7
  • Std Package Width MM: 170.18
  • Std. Pkg. UOM: Piece
  • UOM EA PK: PK
  • Std. Pkg. Qty.: 1000
  • GTIN Carton: 50074983541435
  • Standard Carton Volume Ft3: 0.0637
  • Standard Carton Weight Pounds: 31.2780
  • Std Carton Height In: 11.25
  • Std Carton Height MM: 285.75
  • Std Carton Length In: 23.3
  • Std Carton Length MM: 259.08
  • Std Carton Width In: 10.45
  • Std Carton Width MM: 265.43
  • Std Ctn Qty: 25000
  • Min. Order UOM: Piece
  • Country of Origin 2Digit: CR
  • RoHS Compliant: Compliant
  • EAN: 00074983541430
  • REACH Status: False
  • California Pro65 Cancer: No
  • Buy American Compliant: Y
  • ARRA Compliant: Y
  • Mercury Content Indicator: No
  • Lead Content Indicator: N
  • Restricted Use of Hazardous Substances: N
  • Hazardous Material Flag: N
  • Min Order Qty: 1,000

Overview

UPC 07498354143
GTiN 00074983541430
Length 4 in
Width 0.098 in
Color Aqua
Type Miniature, Locking, External Toothing
Thickness 0.043 in
Material TEFZEL
Country of Origin Costa Rica
Pkg Qty 1000
Family Brand Name Panduit
Carton Qty 25000
Max Operating Temperature 338 degrees F
Overall Length 3.9 in
Standard Packaging Qty 1000/Pack
Min Operating Temperature -76 degrees F
Tensile Strength 18 lb
Bundle Diameter 0.87 in
Sub Brand Pan-Ty
CA Prop65 Warning No
Applications Radiation Resistant
