PAN R100X150V1C P1 Turn-Tell Cass,1
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$64.65/ea
Usually ships within 6 to 10 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Panduit
Mfg Catalog # R100X150V1C
North Coast Part # 663798

Specifications

  • Product Segment: IEI
  • Note: For use with LS8E and LS8EQ printers
  • Product Type: Label Cassette
  • Sub Brand: P1™
  • Cable Type: Category 5e/6/6e UTP and Category 5e FTP
  • Compatible Wire Gauge (AWG): 10-6
  • Color: White
  • Material: Vinyl
  • Number of Labels per Cassette: 100
  • Standards Met: RoHS Compliant
  • Label Length (mm): 38.1
  • Label Length (In.): 1.5
  • Label Width (In.): 1
  • Label Width (mm): 25.4
  • Label Height (mm): 38.1
  • Maximum Cable Diameter (mm): 7.1
  • Label Height (In.): 1.5
  • Maximum Cable Diameter (In.): 0.28
  • Minimum Cable Diameter (In.): 0.22
  • Minimum Cable Diameter (mm): 5.6
  • Print-On Area Height (mm): 12.7
  • Minimum Operating Temperature (°C): -40
  • Print-On Area Height (In.): 0.5
  • Minimum Operating Temperature (°F): -40
  • Maximum Operating Temperature (°F): 200
  • Maximum Operating Temperature (°C): 93

Packaging Details

  • UPC: 07498321944
  • GTIN Package: 00074983219445
  • Standard Package Volume Ft3: 0.0873
  • Standard Package Weight Pounds: 0.2950
  • Std Package Height In: 1.95
  • Std Package Height MM: 49.53
  • Std Package Length In: 4.35
  • Std Package Length MM: 110.49
  • Std Package Width In: 2.85
  • Std Package Width MM: 72.39
  • Std. Pkg. UOM: Piece
  • UOM EA PK: EA
  • Std. Pkg. Qty.: 1
  • GTIN Carton: 50074983219440
  • Standard Carton Volume Ft3: 0.0873
  • Standard Carton Weight Pounds: 2.9500
  • Std Carton Height In: 5.65
  • Std Carton Height MM: 143.51
  • Std Carton Length In: 10.3
  • Std Carton Length MM: 110.49
  • Std Carton Width In: 6.05
  • Std Carton Width MM: 153.67
  • Std Ctn Qty: 10
  • Min. Order UOM: Piece
  • Country of Origin 2Digit: CR
  • RoHS Compliant: Compliant
  • EAN: 00074983219445
  • REACH Status: False
  • Buy American Compliant: Y
  • ARRA Compliant: Y
  • Mercury Content Indicator: No
  • Hazardous Material Flag: N
  • Min Order Qty: 1

Categories

Overview

UPC 07498321944
GTiN 00074983219445
Width 1 in
Color White
Type Thermal Transfer, Self-Laminating
Material Vinyl
Cable Type Category 5e/6/6e UTP And Category 5e FTP
Country of Origin Costa Rica
Pkg Qty 1
Family Brand Name Panduit
Carton Qty 10
Sub Brand P1, Turn-Tell
Adhesive Type Acrylic Based, Pressure Sensitive
Cable Size 10-6 AWG
Temperature Rating -40 to 200 F
Standard Packaging Qty 1/Pack
