PAN T12FR-C20Y Spiral Wrap, FR, .12

Specifications

• UNSPSC: 39131604
• Product Segment: IEI
• Application: (1) Harness Multiple Cables Into a Single Manageable Bundle(2) Allows Breakouts of Single/Multiple Cables(3) Provides Abrasion Protection for Wire, Cables, Hoses, and Tubing
• Product Type: Spiral Wrap
• Note: T12FR-C20Y replaces T12FR-C20
• Color: Black
• Flammability Rating: V-0
• Includes: Installation Tool
• Material: Polyethylene
• Resistance Properties: Flame Resistant
• Maximum Bundle Diameter (mm): 12.7
• Maximum Bundle Diameter (In.): 0.5
• Maximum Operating Temperature (°C): 50
• Maximum Operating Temperature (°F): 122
• Minimum Bundle Diameter (In.): 0.06
• Minimum Bundle Diameter (mm): 1.6
• Minimum Operating Temperature (°C): -20
• Minimum Operating Temperature (°F): -4
• Outer Diameter (In.): 0.12
• Outer Diameter (mm): 3
• Overall Length (m): 152.4
• Overall Length (ft.): 500
• Standards Met: UL Recognized E141152
• Wall Thickness (mm): 0.8
• Wall Thickness (In.): 0.03

Packaging Details

• UPC: 07498310781
• GTIN Package: 00074983107810
• Standard Package Volume Ft3: 0.0648
• Standard Package Weight Pounds: 0.7000
• Std Package Height In: 1.9
• Std Package Height MM: 48.26
• Std Package Length In: 8.85
• Std Package Length MM: 224.79
• Std Package Width In: 8.55
• Std Package Width MM: 217.17
• Std. Pkg. UOM: Roll
• UOM EA PK: EA
• Std. Pkg. Qty.: 1
• Standard Carton Volume Ft3: 0.0648
• Standard Carton Weight Pounds: 0.0000
• Std Carton Length MM: 224.79
• Std Ctn Qty: 0
• Min. Order UOM: Roll
• Country of Origin 2Digit: US
• RoHS Compliant: Compliant
• EAN: 00074983107810
• REACH Status: False
• Buy American Compliant: Y
• ARRA Compliant: Y
• Mercury Content Indicator: No
• Hazardous Material Flag: N
• Min Order Qty: 1
• Pallet Quantity: 0
• Pallet Volume: 0.000000
• Pallet Weight: 0.0000
