RAB ALEDFC52 LED AREA LIGHT 52W FUL
$768.38/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer RAB Lighting
Mfg Catalog # ALEDFC52
North Coast Part # 877745

Features

  • 75% energy savings
  • Superior heat sinking with die cast aluminum housing and external fins
  • 100,000-hour LED lifespan
  • 5-Year, No-Compromise Warranty

Specifications

Performance

  • Watts: 52W
  • Color Temp: 5000K (Cool)
  • Lumens: 7,325
  • Efficacy: 128.5 lm/W
  • Color Accuracy: 72 CRI
  • L70 Lifespan: 100,000 hours
  • Type: Constant Current
  • 120V: 0
  • 208V: 0
  • 240V: 0
  • 277V: 0
  • Input Watts: 57.00W

Dimensions

  • Weight: 29.1 lbs

Listings

  • UL Listing: Suitable for wet locations. Suitable for mounting within 4 feet of the ground.
  • IESNA LM-79 & IESNA LM-80 Testing: RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
  • DLC Listed: This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. DLC Product Code: P0000170T

LED Characteristics

  • Lifespan: 100,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations
  • LEDs: Two (2) multi-chip, high-output, long-life LEDs
  • Color Consistency: 7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
  • Color Stability: LED color temperature is warrantied to shift no more than 200K in CCT over a 5-year period
  • Color Uniformity: RAB's range of CCT (Correlated Color Temperature) follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Construction

  • IES Classification: The Type III distribution is ideal for roadway, general parking and other area lighting applications where a larger pool of lighting is required. It is intended to be located near the side of the area, allowing the light to project outward and fill the area.
  • Ambient Temperature: Suitable For use in 40°C (104°F)
  • Cold Weather Starting: Minimum starting temperature is -40°C (-40°F)
  • Housing: Precision die cast aluminum housing, lens frame
  • Arm: Die-cast aluminum with wiring access plate
  • Effective Projected Area: EPA = 1.5
  • Gaskets: High-temperature silicone
  • Finish: Formulated for high durability and long-lasting color
  • Green Technology: Mercury and UV free. RoHS-compliant components.

Electrical

  • Driver: Constant Current, 720mA, Class 2, 100 - 277V, 50 - 60 Hz, 100 - 277VAC .8 Amps.
  • THD: 6.24% at 120V, 7.1% at 277V
  • Power Factor: 99.3% at 120V, 97.2% at 277V
  • Surge Protection: 6kV

Other

  • Patents: The ALED design is protected by patents pending in the U.S., Canada, China, Taiwan and Mexico.
  • Equivalency: Equivalent to 250W Pulse Start Metal Halide
  • Warranty: RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at
  • Buy American Act Compliance: RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.

Optical

  • BUG Rating: B1 U0 G1

Overview

UPC 01981302933
GTiN 00019813029337
Finish Bronze
Voltage 277 Volt
Type AREA Light
Applications OUTDOOR
Mounting Type 20
Weight 29.1 lb
Wattage 52 Watt
Color Temperature 5000 K
Color Accuracy 72 CRI
Lumens 7,325 lm
Family Brand Name Rab Design Lighting
Lamp Type LED
Fixture Type LED Area Lights
Average Rated Life 100,000 hr
Input Wattage 57.00 W
Power Factor 99.3% At 120V,97.2% At 277V
Efficacy 128.5 LPW
Total Harmonic Distortion 7.1% At 277V,6.24% At 120V
