Manufacturer RAB Lighting
Mfg Catalog # ARBAY2-125N
North Coast Part # 1434210


  • High efficiency. Low price.
  • Available with factory-installed Lightcloud controls
  • Ideal for industrial warehouse spaces
  • 50,000 hour LED lifespan
  • 5-Year, Limited Warranty



  • Watts: 125W
  • Color Temp: 4000K (Neutral)
  • Lumens: 17,441
  • Efficacy: 134.9 lm/W
  • Color Accuracy: 84 CRI
  • L70 Lifespan: 50,000 hours
  • Type: Constant Current
  • 120V: 1.09A
  • 208V: 0.65A
  • 240V: 0.56A
  • 277V: 0.46A
  • Input Watts: 129.30W


  • Weight: 16.5 lbs


  • UL Listed: Suitable for damp locations
  • IESNA LM-79 & LM-80 Testing: RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
  • DLC Listed: This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. DLC Product Code: PGAW7XBQ

LED Characteristics

  • Lifespan: 50,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations
  • LEDs: Long-life, high-efficiency, surface mount LEDs
  • Color Uniformity: RAB's range of CCT (Correlated Color Temperature) follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.


  • Driver: Constant Current, Class 2, 120-277V, 50/60Hz, 120V: 1.09A, 208V: 0.65A, 240V: 0.56A, 277V 0.46A
  • Dimming Driver: Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims as low as 10%.
  • THD: 7.6% at 120V, 8.1% at 277V
  • Power Factor: 99.5% at 120V, 96.5% at 277V
  • Surge Protection: 4kV


  • Operating Temperature: -20°C (-4°F) - 55°C (131°F)
  • Housing: Die formed painted steel
  • Lens: Diffused Polymethyl Methacrylate (PMMA)
  • Mounting: V hooks and optional pendant mounting. AEROBAY™ comes with two 42" chains.
  • Finish: Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color
  • Green Technology: Mercury and UV free. RoHS-compliant components.


  • Replacement: 125W replaces up to (6) F32T8, (4) F54T5 or 400W HID
  • 5 Yr Limited Warranty: The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at
  • Buy American Act Compliance: RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.


GTiN 00019813605807
Finish Polyester Powder Coating
Operating Temperature -4 degrees F
Voltage 120/277 Volt
Type BAY Lighting
Applications INDOOR
Weight 16.5 lb
Wattage 125 Watt
Color Temperature 4000 K
Color Accuracy 84 CRI
Lumens 17441 lm
Family Brand Name Rab Design Lighting
Amperage 0.46 Amp
Average Rated Life 50,000 hr
Input Wattage 129.30 W
Power Factor 96.5% At 277V,99.5% At 120V
Efficacy 134.9 LPW
Total Harmonic Distortion 7.6% At 120V,8.1% At 277V
Product UPC 01981360580
