RAB BLED2X5-18Y LED BOLLARD 18 " 2X
$504.41/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer RAB Lighting
Mfg Catalog # BLED2X5-18Y
North Coast Part # 1008260

Features

  • High output LED
  • 100,000-hour life
  • Superior heat sinking with die cast aluminum housing
  • Meets ADA Requirements

Specifications

Performance

  • Watts: 5W
  • Color Temp: 3000K (Warm)
  • Lumens: 256
  • Efficacy: 24.4 lm/W
  • Color Accuracy: 87 CRI
  • L70 Lifespan: 100,000 hours
  • Type: Constant Current
  • 120V: 0.2A
  • 208V: 0.12A
  • 240V: 0.1A
  • Input Watts: 10.50W

Dimensions

  • Weight: 9.3 lbs

Listings

  • UL Listing: Suitable for wet locations
  • IESNA LM-79 & IESNA LM-80 Testing: RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
  • Dark Sky Conformance: Conforms to (allows for conformance to) the requirements for the IDA's "Fixture Seal of Approval" as of March 1, 2016.

LED Characteristics

  • Lifespan: 100,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations
  • Color Temperature (Nominal CCT): 3000K (Warm)
  • Lumen Maintenance: The LED will deliver 70% of its initial lumens at 100,000 hours of operation
  • Color Consistency: 3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
  • Color Stability: LED color temperature is warrantied to shift no more than 200K in CCT over a 5-year period
  • Color Uniformity: RAB's range of CCT (Correlated Color Temperature) follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Construction

  • Housing: Precision die cast aluminum housing, lens frame
  • Mounting: 18" Bollard
  • Cold Weather Starting: Minimum starting temperature is -40°C (-40°F)
  • Maximum Ambient Temperature: Suitable for use in 40°C (104°F)
  • Gaskets: High-temperature silicone
  • Finish: Formulated for high durability and long-lasting color
  • Anchor Bolt: The anchor bolts for the BLED's have the following dimensions 1/2 - 13 x 12 1/4" long with 2 3/4" hook.
  • Green Technology: Mercury and UV free. RoHS-compliant components.

Other

  • Warranty: RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at
  • Buy American Act Compliance: RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.

Electrical

  • Driver: Multi-chip 2x5W high output long life LED Driver Constant Current, Class II, 120V-240V, 50/60 Hz, 400mA

Overview

UPC 01981302753
GTiN 00019813027531
Finish Bronze
Voltage 120/277 Volt
Type BOLLARD
Applications OUTDOOR
Weight 9.3 lb
Wattage 5 Watt
Color Temperature 3000 K
Color Accuracy 87 CRI
Lumens 256 lm
Family Brand Name Rab Design Lighting
Lamp Type LED
Amperage 0.12 Amp
Average Rated Life 100,000 hr
Input Wattage 10.50 W
Efficacy 24.4 LPW
