Usually ships within 11 to 17 Days
Already a Customer? Log in to view your pricing
Manufacturer RAB Lighting
Mfg Catalog # FXLED300SFB46/PCT
North Coast Part # 1830842


  • 300W replaces 1000 MH floodlights
  • 100,000-hour LED lifespan
  • 5-Year, No-Compromise Warranty



  • Watts: 300W
  • Color Temp: 5000K (Cool)
  • Lumens: 41,990
  • Efficacy: 130 lm/W
  • Color Accuracy: 72 CRI
  • L70 Lifespan: 100,000 hours
  • Type: Constant Current
  • 120V: 2.65A
  • 208V: 1.59A
  • 240V: 1.38A
  • 277V: 1.17A
  • Input Watts: 322.90W


  • Weight: 66.1 lbs


  • UL Listing: Suitable for wet locations. Suitable for ground mounting.
  • IESNA LM-79 & LM-80 Testing: RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
  • DLC Listed: This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. DLC Product Code: PEYBTXT8


  • NEMA Type: NEMA Beam Spread of 4H x 6V

LED Characteristics

  • Lifespan: 100,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations
  • LEDs: Multip-chip, high-output, long-life LEDs
  • Color Consistency: 7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
  • Color Stability: LED color temperature is warrantied to shift no more than 200K in CCT over a 5-year period
  • Color Uniformity: RAB's range of CCT (Correlated Color Temperature) follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.


  • IP Rating: Ingress Protection rating of IP66 for dust and water
  • Maximum Ambient Temperature: Suitable for use in 40°C (104°F)
  • Effective Projected Area: EPA = 4
  • Cold Weather Starting: Minimum starting temperature is -40°C (-40°F)
  • Thermal Management: Superior thermal management with external "Air-Flow" fins
  • Lens: Tempered glass lens
  • Housing: Die-cast aluminum housing and door frame
  • Mounting: Heavy-duty slipfitter for 2 3/8"OD pipe
  • Reflector: Specular and semi-specular vacuum-metalized polycarbonate
  • Gaskets: High-temperature silicone gaskets
  • Finish: Formulated for high durability and long-lasting color
  • Green Technology: Mercury and UV free. RoHS-compliant components.


  • Drivers: Constant Current, 1050mA, 50/60 Hz, 120-277V, 4 kV surge protection, 120V: 2.65A, 208V: 1.59A, 240V: 1.38A, 277V: 1.17A, THD <20%, Power Factor: 99%
  • THD: 8.16% at 120V, 11.91% at 277V
  • Power Factor: 99.4% at 120V, 96.8% at 277V
  • Note: All values are typical (tolerance +/- 10%)
  • Photocell: 120-277V twistlock photocell included. Photocell is compatible with 120-277V.


  • Warranty: RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at
  • Equivalency: Equivalent to 1500W Metal Halide
  • Buy American Act Compliance: RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.


GTiN 00019813254050
Finish Bronze
Voltage 120/277 Volt
Applications OUTDOOR
Weight 66.1 lb
Wattage 300 Watt
Color Temperature 5000 K
Color Accuracy 72 CRI
Lumens 41990 lm
Family Brand Name Rab Design Lighting
Amperage 1.17 Amp
Average Rated Life 100,000 hr
Input Wattage 322.90 W
Power Factor 96.8% At 277V,99.4% At 120V
Efficacy 130 LPW
Total Harmonic Distortion 11.91% At 277V,8.16% At 120V
Product UPC 01981325405
