Manufacturer RAB Lighting
Mfg Catalog # MDLED2X12D10-20Y-B-W
North Coast Part # 1686214

Features

  • Two 12 Watt LED heads
  • Fixture heads rotate a full 360° and tilt up to 45°
  • Easily lock heads in place with a thumb screw
  • Tool-less adjustment for 3 discrete positions: full recess, flush mount or semi-recessed

Specifications

Performance

  • Watts: 24W
  • Color Temp: 3000K (Warm)
  • Lumens: 1,774
  • Efficacy: 57.6 lm/W
  • Color Accuracy: 90 CRI
  • L70 Lifespan: 0 hours
  • Type: Constant Current
  • 120V: 0.24A
  • 208V: 0.16A
  • 240V: 0.14A
  • 277V: 0.12A
  • Input Watts: 30.80W

Dimensions

  • Weight: 5.1 lbs

Listings

  • UL Listing: Suitable for damp locations
  • IESNA LM-79 & LM-80 Testing: RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

Construction

  • IC Rating: Suitable for direct contact with insulation
  • Gear Tray Component: This component must be ordered with Remodeler or New Construction housing in order to make a complete fixture.
  • Brackets: Butterfly brackets allow mounting with 1/4 x 1/2" bar stock, C Channel, 1/2" conduit, or nailer bars
  • Cold Weather Starting: The minimum starting temperature is -10°C/14°F Ambient Temperature
  • Lens: Nanostructure lens eliminates "hot spots", and provides smooth, uniform light at higher efficiency
  • Reflector: 20°
  • Color Gels: MDLED works great with third-party color gels to achieve a dramatic effect or a subtle accent. Plus, cool running LED won't degrade the gels like hot halogen lamps.
  • Tray and Heads: Professional-grade, die-cast aluminum construction
  • Finish: Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color
  • Green Technology: Mercury and UV free. RoHS-compliant components.

Electrical

  • Driver: 0-10V, Constant Current, Class 2, 120-277V, 50/60Hz,350mA, 120V 0.17A, 277V 0.09A, Power Factor 99.4%, THD≤10%, Minimum Operating Temp 14° F (-100°C).
  • Dimming Driver: 0-10V compatible dimmer as low as 10%.

LED Characteristics

  • LED: High-output, long-life LED with 2 step binning and integrated driver technology
  • Color Consistency: 2-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
  • Color Stability: LED color temperature is warrantied to shift no more than 200K in CCT over a 5-year period

Other

  • Warranty: RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at
  • Buy American Act Compliance: RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.

Overview

UPC 01981321524
GTiN 00019813215242
Finish Polyester Powder Coating
Type DOWNLight
Applications INDOOR
Weight 5.1 lb
Wattage 24 Watt
Color Temperature 3000 K
Color Accuracy 90 CRI
Lumens 1774 lm
Family Brand Name Rab Design Lighting
Amperage 0.12 Amp
Input Wattage 30.80 W
Efficacy 57.6 LPW
Color Black Tray White Head
