Usually ships within 11 to 17 Days
Already a Customer? Log in to view your pricing
Manufacturer RAB Lighting
Mfg Catalog # VXLED26DG/UP
North Coast Part # 878082


  • Specially designed for mounting as an uplight
  • 100,000-hour life based on LM-80 results and TM-21 calculations
  • Die Cast Aluminum Housing
  • Classic design with state of the art LED technology
  • Frosted globe emits uniform glow



  • Watts: 26W
  • Color Temp: 4900K (Cool)
  • Lumens: 2,004
  • Efficacy: 73.9 lm/W
  • Color Accuracy: 68 CRI
  • L70 Lifespan: 100,000 hours
  • Type: Constant Current
  • 120V: 0.25A
  • 208V: 0.14A
  • 240V: 0.13A
  • 277V: 0.11A
  • Input Watts: 27.10W


  • Weight: 4.4 lbs


  • UL Listing: Suitable for wet locations. Suitable for mounting within 1.2m (4ft) of the ground.
  • IESNA LM-79 & LM-80 Testing: RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

LED Characteristics

  • Lifespan: 100,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations
  • LED: Multi-chip 26W high-output, long-life LED
  • Color Temperature: 4900K
  • Color Consistency: 7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
  • Color Stability: LED color temperature is warrantied to shift no more than 200K in CCT over a 5-year period
  • Color Uniformity: RAB's range of CCT (Correlated Color Temperature) follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C38.377-2011.


  • Cold Weather Starting: Minimum starting temperature is -40°C (-40°F)
  • Ambient Temperature: Suitable For use in 40°C (104°F)
  • Housing: All die-cast aluminum construction
  • Gaskets: High-temperature silicone
  • Finish: Natural shot blasted aluminum
  • Mounting: (3) 1/2" NPS conduit entry points
  • Guard and Globe: Shot blasted guard with frosted globe
  • Green Technology: Mercury and UV free. RoHS-compliant components.


  • Equivalency: Equivalent to 200W Incandescent
  • Patents: The design of the LVAPOR is protected by the following patents US pat. pending; D651738 CN ZL201230040341.3; ZL201130028360.X, TW pat. 101301367 MX 35699; pat. pending CA.
  • Warranty: RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at
  • Buy American Act Compliance: RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.


  • Driver: Constant Current, 100V-277V, 50/60 Hz, 0.48 Amp, THD is less than or equal to 20% Power Factor 97.9%.
  • THD: 6.1% at 120V, 10.1% at 277V


UPC 01981304182
GTiN 00019813041827
Finish Bronze
Voltage 120/277 Volt
Applications INDOOR
Mounting Type Ceiling
Weight 4.4 lb
Wattage 26 Watt
Color Temperature 4900 K
Color Accuracy 68 CRI
Lumens 2004 lm
Family Brand Name Rab Design Lighting
Lamp Type LED
Amperage 0.11 Amp
Average Rated Life 100,000 hr
Input Wattage 27.10 W
Efficacy 73.9 LPW
Total Harmonic Distortion 10.1% At 277V,6.1% At 120V
