RAB WP2LED24W/PC WAL 24W COOL 120V

Features

• Covers footprint of traditional HID wall packs
• WP2LED replaces up to 175W MH
• 100,000-Hour LED lifespan

Specifications

Performance

• Watts: 24W
• Color Temp: 5000K (Cool)
• Lumens: 2,998
• Efficacy: 122.4 lm/W
• Color Accuracy: 83 CRI
• L70 Lifespan: 100,000 hours
• Type: Constant Current
• 120V: 0.2A
• Input Watts: 24.50W

Dimensions

• Weight: 9.6 lbs

Listings

• UL Listing: Suitable for wet locations. Wall mount only.
• IESNA LM-79 & LM-80 Testing: RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
• DLC Listed: This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. DLC Product Code: P45YDNAR

Optical

• BUG Rating: B1 U3 G3

Construction

• Thermal Management: Superior thermal management with die-cast aluminum heatsink
• Maximum Ambient Temperature: Suitable for use in 40°C (104°F)
• Cold Weather Starting: Minimum starting temperature is -40°C (-40°F)
• Housing: Precision die-cast aluminum housing
• Mounting: Die-cast backbox with four (4) conduit entry points and knockout pattern for junction box or direct wall mounting. Hinged door for easy re-assembly.
• Lens: Prismatic, heat-resistant borosilicate glass
• Reflector: High-gloss white aluminum
• Gaskets: High-temperature silicone gaskets
• Finish: Formulated for high durability and long-lasting color
• Green Technology: Mercury and UV free. RoHS-compliant components.

Electrical

• Driver: Constant Current, Class 2, 450mA, 50/60 Hz. 100 - 277V, 4kV surge protection
• Photocell: 120V Button Photocell Included. Photocell is only compatible with 120V.

LED Characteristics

• Color Stability: LED color temperature is warrantied to shift no more than 200K in CCT over a 5-year period
• Color Uniformity: RAB's range of CCT (Correlated Color Temperature) follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Other

• Warranty: RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at
• Equivalency: Equivalent to 70W Metal Halide
• Buy American Act Compliance: RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
