Manufacturer RAB Lighting
Mfg Catalog # X34-55L/120
North Coast Part # 1686439


  • General purpose floodlight
  • Very wide 7H x 7V NEMA distribution
  • Low profile and lightweight
  • IP65 rating protects against dust and water



  • Watts: 52W
  • Color Temp: 5000K (Cool)
  • Lumens: 5,514
  • Efficacy: 99.7 lm/W
  • Color Accuracy: 83 CRI
  • L70 Lifespan: 50,000 hours
  • Type: Constant Current
  • 120V: 0.5A
  • Input Watts: 55.30W


  • Weight: 3.4 lbs


  • UL Listing: Suitable for wet locations. Suitable for ground mounting.
  • IESNA LM-79 & LM-80 Testing: RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
  • DLC Listed: This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. DLC Product Code: PW8AKYYE


  • Driver: Constant Current, 120V, 60 Hz, 120V: 0.466A
  • THD: 14.6% at 120V
  • Power Factor: 98.9% at 120V
  • Surge Protection: 2kV
  • Note: All values are typical (tolerance +/- 10%)


  • NEMA Type: NEMA Beam Spread of 7H x 7V

LED Characteristics

  • LEDs: Long-life, high-efficacy surface mount LEDs
  • Lifespan: 50,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations
  • Color Uniformity: RAB's range of CCT (Correlated Color Temperature) follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.


  • IP Rating: Ingress Protection rating of IP65 for dust and water
  • Cold Weather Starting: Minimum starting temperature is -40°C (-40°F)
  • Maximum Ambient Temperature: Suitable for use in 40°C (104°F)
  • Housing: Die cast aluminum
  • Mounting: Heavy-duty mounting arm with "O" ring seal & stainless steel screw
  • Lens: Tempered glass
  • Finish: Formulated for high durability and long-lasting color
  • Green Technology: Mercury and UV free. RoHS-compliant components.


  • Equivalency: Equivalent to 175W Metal Halide
  • 5 Yr Limited Warranty: The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at
  • Buy American Act Compliance: RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.


UPC 01981374291
Item Long Description X34 Flood, 55W,5500Lm LED 120V, 5000k, 80 CRI, Bronze
GTiN 00019813742915
Weight 3.4 lb
Wattage 52 Watt
Color Temperature 5000 K
Color Accuracy 83 CRI
Lumens 5514 lm
Family Brand Name RAB Design Lighting
Amperage 0.5 Amp
Max Operating Temperature 104 degrees F
Average Rated Life 50,000 hr
Input Wattage 55.30 W
Power Factor 98.9% At 120V
Efficacy 99.7 LPW
Total Harmonic Distortion 14.6% At 120V
Applications OUTDOOR
