RAB YBLED60N/PCU YARD 60W 4K 120-27
$311.01/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer RAB Lighting
Mfg Catalog # YBLED60N/PCU
North Coast Part # 1686121

Features

  • Widespread light distribution illuminates large areas
  • Vandal-resistant
  • High-impact polycarbonate lens
  • Rugged die-cast aluminum housing withstands harsh environments
  • Integrated dusk to dawn photocell
  • 100,000-hour LED lifespan

Specifications

Performance

  • Watts: 60W
  • Color Temp: 4000K (Neutral)
  • Lumens: 7,537
  • Efficacy: 135.3 lm/W
  • Color Accuracy: 75 CRI
  • L70 Lifespan: 100,000 hours
  • Type: Constant Current
  • 120V: 0.52A
  • 208V: 0.30A
  • 240V: 0.26A
  • 277V: 0.22A
  • Input Watts: 55.70W

Dimensions

  • Weight: 8.6 lbs

Listings

  • UL Listing: Suitable for dry and wet locations
  • IESNA LM-79 & IESNA LM-80 Testing: RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
  • DLC Listed: This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. DLC Product Code: PWH7FFES

Electrical

  • Driver: Constant Current, Class 2, 120V-277V, 50/60 Hz, 950mA, 120V: 0.6A, 208V: 0.321A, 240V: 0.278A, 277V: 0.223
  • Dimming Driver: Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims as low as 10%.
  • THD: 8.6% at 120V, 7.9% at 277V
  • Power Factor: 99.6% at 120V, 89.8% at 277V
  • Surge Protection: 4 kV Line-Line, 6 kV Line-Earth
  • Photocell: 120-277V Button Photocell Included. Photocell is compatible with 120V-277V.

LED Characteristics

  • LEDs: Long-life, high-efficiency, surface mount LEDs
  • Lifespan: 100,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations
  • Color Stability: LED color temperature is warrantied to shift no more than 200K in CCT over a 5-year period
  • Color Uniformity: RAB's range of CCT (Correlated Color Temperature) follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Construction

  • IP Rating: Ingress Protection rating of IP66 for dust and water
  • IES Classification: The Type V distribution produces light in a wide and uniform 360° pattern that is perfect for large outdoor areas such as parking lots, corporate parks and retail settings
  • Cold Weather Starting: Minimum starting temperature is -40°C (-40°F)
  • Housing: Precision die-cast aluminum housing and arm
  • Mounting: Mounts on wall or existing arm/pole YARM24 (1 5/8" diameter pipe)
  • Reflector: High-reflectance white paint
  • Lens: Flat polycarbonate lens
  • Gaskets: High-temperature silicone
  • Finish: Formulated for high durability and long-lasting color
  • Green Technology: Mercury and UV free. RoHS-compliant components.

Optical

  • BUG Rating: B3 U3 G2

Other

  • Patents: The design of YBLED26 is protected by patents pending in US, Canada, China, Taiwan and Mexico
  • Warranty: RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at
  • Equivalency: Equivalent to 200 HPS
  • Buy American Act Compliance: RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.

Overview

UPC 01981368173
GTiN 00019813681733
Finish Gray
Voltage 120/277 Volt
Type ROADWAY
Applications OUTDOOR
Mounting Type Wall
Weight 8.6 lb
Wattage 60 Watt
Color Temperature 4000 K
Color Accuracy 75 CRI
Lumens 7,537 lm
Family Brand Name Rab Design Lighting
Amperage 0.3 Amp
Average Rated Life 100,000 hr
Input Wattage 55.70 W
Power Factor 89.8% At 277V,99.6% At 120V
Efficacy 135.3 LPW
Total Harmonic Distortion 8.6% At 120V,7.9% At 277V
Color Silver
