Allen-Bradley 100-D420EN11 IEC 420 A MCS D Contactor
Product image thumbnail 0
Product image thumbnail 1
$5,210.00/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer AB-MCP
Mfg Catalog # 100-D420EN11
North Coast Part # 267237

Features

  • Provides front and side mounting of auxiliary contacts
  • Simplifies selection with electronic wide-range AC/DC coils
  • Includes reversible coil terminations (line or load side)
  • Includes space-saving coil-mounted control modules
  • Offers common accessories for all contactor sizes
  • Includes built-in surge suppression
  • Meets IEC, UL, and CSA standards requirements
  • Reduces drop-out time to 18-23ms, a reduction of up to 50% compared to standard electronic coils
  • Saves energy with low power consumption
  • Provides reversible coil terminations (line or load side)
  • RoHs compliant
  • Complies with RoHs
  • Includes electronic and pneumatic timing modules
  • Provides IP2X finger protection
  • Available integrated PLC interface

Specifications

  • Coil Voltage: 380-415V 50/60Hz / 440-480V 50/60Hz / 500V 50/60Hz Electronic Coil w/ Elec. Interface
  • 3-Phase kW (50 Hz) 230V Rating: 135
  • 3-Phase kW (50 Hz) 400V Rating: 238
  • 3-Phase kW (50 Hz) 415V Rating: 250
  • 3-Phase kW (50 Hz) 500V Rating: 300
  • 3-Phase kW (50 Hz) 690V Rating: 425
  • 3-Phase kW (50 Hz) 1000V Rating: 225
  • 3-Phase HP (60 Hz) 200V Rating: 150
  • 3-Phase HP (60 Hz) 230V Rating: 175
  • 3-Phase HP (60 Hz) 460V Rating: 350
  • 3-Phase HP (60 Hz) 575V Rating: 400

System Voltage Data

  • Phases: Three Phase

Contactor Data

  • Rated Operating Current: 420 A
  • Coil Type: Electronic Coil w/ Electronic Interface
  • Auxiliary Contact Configuration: 1 N.O. 1 N.C.

Overview

UPC 78118010570
GTiN 00781180105708
Type MCS D, Non-Reversing
Standard C-TICK,CCC,CE,CSA,CUL,KC,UL
Coil Voltage 380 - 500 VAC at 50/60 Hz
Family Brand Name Allen Bradley
Number of Phases 3 Phase
Contact Configuration 1 NO - 1 NC Auxiliary
Current 420 A
Sub Brand IEC
Conductor Size (2) 4 AWG - 350 MCM
Mounting Type Panel
Temperature Rating -25 to 60 C
Power Rating 132 kW at 230 V, 238 kW at 400 V, 250 kW at 415 V, 420 kW at 500 V, 425 kW at 690 V, 220 kW at 1000 V
Blade Dimensions 155 mm W x 205 mm D x 180 mm H
Environmental Conditions -40 to 80 deg C Storage Temperature, IEC 60068-2-30 Climatic Withstand, 2000 NN m, per IEC60947-4 Maximum Altitude of Installation Site
Number of Poles 3 Pole
