Allen-Bradley 100-D630EB00 IEC 630 A MCS D Contactor
$9,240.00/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Rockwell / Allen Bradley
Mfg Catalog # 100-D630EB00
North Coast Part # 821272

Specifications

System Voltage Data

  • Phases: Three Phase
  • Coil Voltage: 440-480V 50/60Hz Electronic Coil w/ Elec. Interface
  • 3-Phase kW (50 Hz) 230V Rating: 200
  • 3-Phase kW (50 Hz) 400V Rating: 355
  • 3-Phase kW (50 Hz) 415V Rating: 355
  • 3-Phase kW (50 Hz) 500V Rating: 450
  • 3-Phase kW (50 Hz) 690V Rating: 500
  • 3-Phase kW (50 Hz) 1000V Rating: Null
  • 3-Phase HP (60 Hz) 200V Rating: 200
  • 3-Phase HP (60 Hz) 230V Rating: 250
  • 3-Phase HP (60 Hz) 460V Rating: 500
  • 3-Phase HP (60 Hz) 575V Rating: 600

Contactor Data

  • Rated Operating Current: 630 A
  • Coil Type: Electronic Coil w/ Electronic Interface
  • Control Voltage: 440-480V 50/60Hz
  • Auxiliary Contact Configuration: 0 N.O. 0 N.C.

Features

  • Includes electronic and pneumatic timing modules
  • Simplifies selection with electronic wide-range AC/DC coils
  • Complies with RoHs
  • Includes reversible coil terminations (line or load side)
  • Provides IP2X finger protection
  • Provides front and side mounting of auxiliary contacts
  • Includes built-in surge suppression
  • Reduces drop-out time to 18-23ms, a reduction of up to 50% compared to standard electronic coils
  • Offers common accessories for all contactor sizes
  • Includes space-saving coil-mounted control modules
  • Meets IEC, UL, and CSA standards requirements
  • RoHs compliant
  • Available integrated PLC interface
  • Provides reversible coil terminations (line or load side)
  • Saves energy with low power consumption

Categories

Overview

UPC 78118050410
GTiN 00781180504105
Type MCS D, Non-Reversing
Standard C-TICK,CCC,MARINE
Coil Voltage 440 - 480 VAC at 50/60 Hz
Control Voltage 440/480 V
Family Brand Name Allen Bradley
Number of Phases 3 Phase
Contact Configuration 0 N.O. 0 N.C.
Current 630 A
Sub Brand IEC
Conductor Size (2) 2/0 AWG - 500 MCM
Mounting Type Panel
Temperature Rating -25 to 60 C
Power Rating 200 kW at 230 V, 355 kW at 400 V, 415 V, 500 kW at 500 V, 690 V
Blade Dimensions 255 mm W x 310 mm D x 265 mm H
Environmental Conditions -40 to 80 deg C Storage Temperature, IEC 60068-2-30 Climatic Withstand, 2000 NN m, per IEC60947-4 Maximum Altitude of Installation Site
Number of Poles 3 Pole
