A-B 1485C-P1M5-C DeviceNet Physical
Product image thumbnail 0
Product image thumbnail 1
$93.60/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer AB-SEN
Mfg Catalog # 1485C-P1M5-C
North Coast Part # 264002

Features

  • Ratcheting coupling nut resists vibration
  • Polyvinylchloride (PVC) jacket resists oil and chemicals
  • Watertight connections (NEMA 4, 6P; IP 67)
  • Gold plated contacts

Specifications

  • Armour: Thick Media, Grey PVC
  • Connector: Standard - Epoxy Coated Zinc
  • Number Of Pins: Standard 5-pin

Cable Data

  • Cable Type: Thick Media, Grey PVC
  • Coupling Nut Material: Standard - Epoxy Coated Zinc
  • Cable Details: Standard Passive Cable
  • Standard or Build-to-Order Cable Length: 1 meter (3.28 feet)
  • First End Connector Style: Mini, Straight Male
  • Number of Pins: Standard 5-pin

Device End Data

  • Second End Termination Style: Cable
  • Second End Conductors: Standard 5 leads

Overview

UPC 61132013864
GTiN 00611320138641
Length 0-3 m
Type Thick
Connection Type Standard - Epoxy Coated Zinc
Number of Pins 5
Family Brand Name Allen Bradley
Construction Thick Media, Grey PVC,Standard - Epoxy Coated Zinc
Color Gray
Number of Conductors 5
Connector Type Mini Straight Male x 5-Lead Cable
Temperature Rating -20 to 70 C
Enclosure Type NEMA 1, 2, 3, 4, 6P, 12, 13
Cable Length 1 m
Bend Radius 122 mm
Used With DeviceNet Physical Media System
Sub Brand DeviceNet
Standard KC
