Allen-Bradley 1485R-P2F5-C Trunk End Micro Right Angle Male Device End Cable, Thin Media Yellow Cpe Devicenet
Product image thumbnail 0
Product image thumbnail 1
$76.01/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer AB-SEN
Mfg Catalog # 1485R-P2F5-C
North Coast Part # 335284

Specifications

  • Armour: Thin Media, Yellow CPE
  • Connector: Standard - Epoxy Coated Zinc
  • Number Of Pins: Standard 5-pin

Cable Data

  • Cable Type: Thin Media, Yellow CPE
  • Coupling Nut Material: Standard - Epoxy Coated Zinc
  • Cable Details: Standard Passive Cable
  • Standard or Build-to-Order Cable Length: 2 meters (6.56 feet)
  • First End Connector Style: Micro, Right Angle Male
  • Number of Pins: Standard 5-pin

Device End Data

  • Second End Termination Style: Cable
  • Second End Conductors: Standard 5 leads

Overview

UPC 66207278915
GTiN 00662072789155
Length 0-3 m
Type Standard, Thin
Connector Type 5-Pin Micro Right Angle Male x 5-Lead Cable
Connection Type Standard - Epoxy Coated Zinc
Number of Pins 5
Family Brand Name Allen Bradley
Construction Thin Media, Yellow CPE,Standard - Epoxy Coated Zinc
Color Yellow
Material Brass Contact, Epoxy Coated Zinc Coupling Nut
Number of Conductors 5
Temperature Rating -20 to 70 C
Enclosure Type NEMA 1, 2, 3, 4, 6P, 12, 13
Cable Length 2 m
Bend Radius 69 mm
Used With DeviceNet Round Media System
Sub Brand DeviceNet
Standard CUL,KC,UL
