Allen-Bradley 1492-JD3FB 2-1/2 mm Double Level Fuse Block
Product image thumbnail 0
Product image thumbnail 1
$13.27/ea
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer AB-GIA
Mfg Catalog # 1492-JD3FB
North Coast Part # 421586

Features

  • Backed-out screws
  • Self-locking screw type clamp design
  • Four-sided funnel wire guides
  • Wide range of accessories available
  • Tin-plated terminal and zinc chromate steel screws
  • Finger-safe housing
  • Nickel-plated terminals and stainless steel screws

Specifications

  • Special Features: Hinged-arm fuse circuit

Block Style

  • Base Block Style: Fuse Blocks

Base Data

  • Base Block Type: Two-Level Block

Detail Data

  • Features: Hinged-arm fuse circuit
  • Maximum Wire Size & Rating: Fuse Circuit: UL: 22-12 AWG (10A @300V AC/DC) CSA: 26-12 AWG (10A/250V @300V AC/DC) IEC: 4.0mm² (6.3A @500V AC/DC) Feed-through circuit: UL: 22-12 AWG (20A @300V AC/DC) CSA: 26-12 AWG (25A @300V AC/DC) IEC: 4.0mm² (6.3A @500V AC/DC)
  • Color: Gray (Standard)
  • Voltage Rating: 500V/600V AC/DC

Overview

UPC 66207473446
GTiN 00662074734467
Color Grey
Voltage 500 Volt
Type Double Level
Terminal Type Screw
Mounting Type 35 mm DIN Rail
Wire Size 14 AWG
Temperature Rating -50 to 120 C
Family Brand Name Allen Bradley
Terminal Size 8 x 76.2 x 48mm (0.31 x 3.0 x 1.89 in)
Blade Dimensions 76.2 mm W x 48 mm H
Sub Brand 1492
Standard CCC,CE,CSA,KC,UL
Amperage 10 Amp
