A-B 1492-JD3RB121 1492 IEC Screw Te
Product image thumbnail 0
Product image thumbnail 1
$10.07/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer AB-GIA
Mfg Catalog # 1492-JD3RB121
North Coast Part # 1497801

Specifications

Block Style

  • Base Block Style: Internal Component Blocks

Base Data

  • Base Block Type: Two-Circuit Feed-Through Block

Detail Data

  • Features: Two level block with a selectable resistor value between the 2 levels
  • Maximum Wire Size & Rating: UL: 22-12 AWG (20A Busbar @600V AC/DC) CSA: 26-12 AWG (10A Busbar @300V AC/DC) IEC: 2.5mm² @152V AC/DC
  • Color: Gray (Standard)
  • Resistor Value: 120 Ohm Resistance

Categories

Overview

UPC 78118014179
Item Long Description 1492 IEC Screw Terminal Block
GTiN 00781180141799
Color Gray
Family Brand Name Allen Bradley
Terminal Type Screw
Conductor Size 24-12 AWG
Mounting Type Rail
Connection Type Screw
Temperature Rating -50 to 120 C
Power Rating 0.25 W
Blade Dimensions 2.72 in W x 0.20 in D x 2.19 in H
Torque Rating 4.4 - 8.8 in-lb
