Allen-Bradley 1492-L3Q-B 2-1/2 mm Standard Terminal Block
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$1.98/ea
In Stock | 59 available at 1 location
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer AB-GIA
Mfg Catalog # 1492-L3Q-B
North Coast Part # 65131

Features

  • Screwless termination technology
  • Secure contact is durable under extreme conditions
  • Maintenance-free, no need to retighten
  • Requires only a flat-head screwdriver for installation
  • Helps reduce wiring time by more than 50%
  • Wide range of accessories available

Specifications

  • Special Features: 2 Connection points on each side

Block Style

  • Hazardous Location: No
  • Base Block Style: Standard Feed-Through Blocks

Base Data

  • Base Block Type: One-Circuit Feed-Through Block

Detail Data

  • Features: 2 Connection points on each side
  • Maximum Wire Size & Rating: UL: 30-12 AWG (25A @600V AC/DC) CSA: 26-12 AWG (27A @600V AC/DC) IEC: 2.5mm² (24A @800V AC/DC) EEx e II: 2.5mm²/20-12 AWG (21A @550V AC/DC)
  • Color: Blue

Overview

UPC 66207305490
Item Long Description IEC Term Blck 5.1x79x31.3mm Spr Clp
GTiN 00662073054900
Color Blue
Type Feed-Through
Wire Size 30-12 AWG
Connection Type Spring Clamp
Family Brand Name Allen Bradley
Terminal Size 5.1 x 79 x 31.3mm (0.20 x 3.11 x 1.23 in)
Blade Dimensions 5.1 x 79 x 31.3 mm
Sub Brand 1492
Voltage 550 Volt
Standard CCC,CE,CSA,CUL,KC,MARINE,UL
Amperage 21 Amp
