Allen Bradley 1492-W4-BL 600 VAC/VDC 30 Amp 22 to 10 AWG Black Standard Feed-Through Terminal Block
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Usually ships within 11 to 17 Days
Already a Customer? Log in to view your pricing
Manufacturer Allen-Bradley / Rockwell
Mfg Catalog # 1492-W4-BL
North Coast Part # 151483


  • Copper current bar and tin-plated surface
  • Four-sided funnel wire guides
  • Self-locking screw type clamp design
  • Counter-sinking of clamping screws
  • Finger-safe housing
  • Backed out screws
  • Easy installation or removal from both sides of DIN Rail
  • Backed-out screws
  • Compatible with several high visibility snap-in marker cards
  • Tin-plated terminal and zinc chromate steel screws
  • Wide range of accessories available


  • Special Features: Single-circuit terminal block

Block Style

  • Base Block Style: Standard Feed-Through Blocks

Base Data

  • Base Block Type: Space-Saver Feed-Through Blocks

Detail Data

  • Features: Single-circuit terminal block
  • Maximum Wire Size & Rating: UL: 22-10 AWG (30A @600V AC/DC) CSA: 22-10 AWG (30A @600V AC/DC) IEC: 4mm² (32A @800V AC/DC) EEx e II: 4mm² (32A @ 550V AC/DC)
  • Color: Black


GTiN 00662468235495
Color Black
Type Single Level
Terminal Type Screw
Mounting Type 35 mm DIN Rail
Wire Size 10 AWG
Temperature Rating -40 to 90 C
Family Brand Name Allen Bradley
Terminal Size 6 x 45.3 x 35mm (0.24 x 1.78 x 1.38 in)
Blade Dimensions 47.6 mm L x 7 mm W x 41 mm H
Sub Brand 1492
Product UPC 66246823549
Voltage 550 Volt
Amperage 30 Amp
