Allen-Bradley 1784-CP7 PLC-5 Communication Adaptor

Features

• Can provide power through only one pair of the four available contacts, so the other available pair can be used for single channel E-stop
• E-stop T-ports and shorting plugs are red for easy identification
• Highly pliable polyvinylchloride (PVC) jacket material
• Many end devices, including Rockwell Automation® hardened I/O products, use a different pin numbering convention for 4-pin mini connections than that used on physical media products
• Both conventions have the same color code going to the same spot but they use a different pin numbering designation
• Sized to fit inside 1-in. conduit
• Physical key to ensure proper connection alignment

Specifications

Data Highway Plus Network

• DH+ Controller Interface Cables: Adapter, CP/CP5 To PLC-5 (DIN)
