Allen Bradley 22C-D460A103 PowerFlex 400 250 kW 350 Hp AC Drive
Product image thumbnail 0
Product image thumbnail 1
$32,618.25/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer AB-CDS
Mfg Catalog # 22C-D460A103
North Coast Part # 345954

Features

  • Supports Drive Serial Interface (DSI) communication modules
  • Premier Integration with PowerFlex® AC drives uses the Logix control platform to simplify parameter and tag programming and reduces development time
  • Packaged drive options include disconnect and contactor bypass packages
  • Drive overload protection, flying start, purge and damper input, hand/off/auto, and sleep/wake features
  • Internal RS-485, Common Industrial Protocol (CIP), embedded Modbus® RTU, Metasys® N2, and Apogee® FLN P1-plant floor network protocols
  • Power ratings:

Specifications

  • Voltage Rating: 480 VAC, 3 PH
  • Enclosure: IP30 (NEMA 1 / UL Type 1)

Base Drive Information

  • Version Voltage Code: 480 VAC, 3 PH
  • Output Current: 460 Amps
  • Human Interface Module: Fixed Keypad
  • Enclosure Style: IP30 (NEMA 1 / UL Type 1)
  • Version: RS485 (without Brake IGBT)
  • Frame Size: Frame Size H

Overview

UPC 82091977955
Item Long Description PowerFlex 400- 250 kW (350 HP) AC Drive
GTiN 00820919779558
Voltage 480 Volt
Type AC Drive
Family Brand Name Allen Bradley
Power Rating 250 kW
TC Connection Fixed Terminal Block
Output Current 460 A
Power Factor 0.98
Enclosure IP30,UL-NEMA Type 1
Sub Brand PowerFlex 400
Mounting Type Panel Mount
Standard C-TICK,CE,CUL,GOST,KC,UL
Frequency 50-60 Hz
Connection Type Fixed Terminal Block
