Allen-Bradley 42KL-W1LB-F4 Minisight Sensor
Product image thumbnail 0
Product image thumbnail 1
Already a Customer? Log in to view your pricing
Manufacturer AB-SEN
Mfg Catalog # 42KL-W1LB-F4
North Coast Part # 17452


  • Durable housing design with 1200 psi washdown rating
  • 18 mm threaded nose- or side-mount through-holes
  • Switch selectable L.O./D.O.
  • Visible indicators for power, output and 2.5x margin/short circuit protection


  • Sensing Beam: Infrared LED
  • Voltage Rating: 10.8-30V DC - LO or DO selectable
  • Output: Both Sink (NPN) and Source (PNP)
  • Connection: 4-pin DC Micro QD on 152mm (6in) pigtail

Photoelectric Sensor Data

  • Operating Version: Standard
  • Sensing Mode: Wide Angle Diffuse
  • Light Source: Infrared LED
  • Operating Voltage/Mode: 10.8-30V DC - LO or DO selectable
  • Output Type: Both Sink (NPN) and Source (PNP)
  • Sensitivity Adjustment: Yes
  • Connection Type: 4-pin DC Micro QD on 152mm (6in) pigtail

Accessory Items

  • Connection Media: DC Micro(M12), Female, Straight, 4-pin PVC, Yellow, Unshielded, 5 m


  • 889D-F4AC-5


UPC 66246871425
GTiN 00662468714259
Voltage 10.8-30 Volt
Type Adjustable Sensitivity, Standard, Compact Rectangular
Connection Type 4-Pin DC Micro Quick Disconnect on 152 mm Pigtail
Operating Voltage 10.8-30V DC - LO or DO selectable
Family Brand Name Allen Bradley
Class Photoelectric sensors
Light Source Infrared
TC Connection 4-pin DC Micro QD on 152mm (6in) pigtail
Output Both Sink (NPN) and Source (PNP)
Sensing Range 7.0 in
Circuit Type NPN Sink/PNP Source
Sub Brand MiniSight
Standard C-TICK
Sensor Type Infrared
