Allen Bradley 440H-S34024 Guardmaster Sprite Hinge Switch
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Usually ships within 11 to 17 Days
Already a Customer? Log in to view your pricing
Manufacturer AB-SFC
Mfg Catalog # 440H-S34024
North Coast Part # 545797


  • Cam-adjustable degree of operation
  • Smallest hinge interlock switch available, 75 X 25 mm
  • Ideal for small, lightweight guards


Hinge Switch Data

  • Product Family: Sprite
  • Contacts (Safety/Auxiliary): 2 Normally Closed / None
  • Shaft Type: Solid
  • Actuator Shaft: Length: 60MM Diameter: 8MM
  • Conduit Entry / Connection Type: M16 Conduit 1/2in Adaptor


  • Standard: IEC 60947-5-1, ISO 14119, ISOTR 12100
  • Pneumatic Fluid: Compressed air or neutral gas
  • Pressure Range: 2 to 8 Bars
  • Connection Type: Push in fittings for standard 4 mm diameter nylon tube, internal diameter 2.5 mm
  • Flow Rate: 138 NL/min.
  • Mechanical Life: 1,000,000 Operations
  • Temperature: 10 to 60 degrees C (50 to 140 degrees F)


UPC 78118006199
Item Long Description Guardmaster Sprite Hinge Switch
GTiN 00781180061998
Type Hinge Switch
Material Plastic
Standard IEC 60947-5-1,ISO 14119,ISOTR 12100
Connection Type Push In Fittings For Standard 4 Mm Diameter Nylon Tube, Internal Diameter 2.5 Mm
Contact Type Not Applicable
Family Brand Name Allen Bradley
TC Connection M16 Conduit, 1/2in. NPT adptr
Actuator Solid Hinge Shaft 60mmx08mm
Contact Configuration 2 N.C. Safety
Sub Brand Guardmaster Sprite
