A-B 440L-C4K1760YD Type4 1760-30mm
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$6,233.47/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer AB-SFC
Mfg Catalog # 440L-C4K1760YD
North Coast Part # 670421

Specifications

Safety Light Curtain Data

  • Type of Unit: Cascading Pair (Transmitter Tx and Receiver Rx)
  • Integrated Laser Alignment: No
  • Protected Height: 1760mm (69.3 in)
  • Resolution: 30mm (1.18in.) Scanning Ranges: 0.3...16m (0.98...52 ft)
  • Beams: 88
  • System Connector: Micro style quick-disconnect M12 (Tx: 4 or 5-pin, Rx: 8-pin)

Additional Details

  • Length: 1876 mm (73.9 in)

Categories

Overview

UPC 61259842505
Item Long Description Type4 1760-30mm GuardShield
GTiN 00612598425051
Length 73.9 in
Type Pair, Type 4, Cascading
Connector Type Micro Quick Disconnector
Family Brand Name Allen Bradley
Enclosure IP65
Sub Brand GuardShield
Material Aluminum Housing, PMMA Cover
Temperature Rating -10 to 55 C
Light Source Infrared 870 nm
TC Connection Micro Quick Disconnect
Response Time 20 - 25 Millisecond Uncoded, 30 - 35 Millisecond Coded
Blade Dimensions 1912 mm L x 52 mm W
Environmental Conditions Up to 95% Humidity, -25 to 75 C Storage
Standard CCC,KC
Connection Type Micro Quick Disconnector
