A-B 45MLA-CT1200P10 Measuring Light
Product image thumbnail 0
Product image thumbnail 1
$2,234.40/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer AB-SEN
Mfg Catalog # 45MLA-CT1200P10
North Coast Part # 819583

Features

  • Detects targets with gaps or spaces
  • Slim housing profile of 15 x 20 mm (0.6 x 0.8 in.)
  • Detects objects regardless of position in sensing field

Specifications

Assembly

  • Please Note: The 45MLA is a "Three Box System"

Array Selection

  • Please Note: Arrays ship as Transmitted Beam Pairs
  • Array Type: Cascadable
  • Sensing Height: 1200 mm (47.2 in)
  • Beam Spacing: 10 mm (0.39 in)
  • Number of Beams: 120

Second Array Selection

  • Please Note: A cascadable 45MLA system includes cascadable arrays and a standard array pair at the end. Configure the end arrays below.

Controller Selection

  • Please Note: An external controller is required

Patchcord Selection

  • Please Note: Quantity of 2 Patchcords Required
  • Please Note: Both the standard array and the cascadable array have 500mm / 19in pigtails

Overview

UPC 61259888747
GTiN 00612598887477
Type Measuring Light Array, Cascadable
Family Brand Name Allen Bradley
Sub Brand Photoswitch
Material Aluminum Housing, Polycarbonate Lens
Connection Type 8-Pin DC Micro (M12) Female QD on 500 mm Cable Pigtail
Temperature Rating 0 - 55 C
Light Source 940 nm
Blade Dimensions 1239 mm H
Environmental Conditions 15 - 95% Relative Humidity, -20 to 70 C Storage Temperature
Voltage 10-30 Volt
Standard KC
