Allen-Bradley 800FM-LSR34 3-Position Red Metal Spring Return From Right Illuminated Selector Switch
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$24.35/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer AB-PBS
Mfg Catalog # 800FM-LSR34
North Coast Part # 753356

Specifications

Selector Switch Data

  • Operator Type: Illuminated Selector Switch
  • Operator Construction: Round Metal (Type 4/13, IP66)
  • Operator Function: Spring Return from Right, 3 Position
  • Knob Color: Red
  • Orientation: Standard
  • Packaging: Standard Pack, Quantity:1

Back Of Panel Data

  • Part Numbers: No Back of Panel Part Numbers
  • Power Module Selection: No Power Module

Categories

Overview

UPC 66207381900
Item Long Description 22mm Selector Switch 800F PB
GTiN 00662073819004
Color Red Knob, White Insert
Type 22mm Selector Switch
Material Metal
Operator Type Illuminated Selector Switch
Family Brand Name Allen Bradley
Actuator Sprg Return from Right, 3 Pos
Orientation Standard Orientation
Sub Brand 800F PB
Size 22.5 mm
Terminal Type Spring Clamp
Conductor Size 18-14 AWG
Temperature Rating -25 to 70 C
Lamp Type LED
Lens Type Round
Contact Material Silver Plated Brass
Blade Dimensions 27.9 mm D x 29.8 mm H
Environmental Conditions 50 - 95% Relative Humidity
Bezel Material Metal
Number of Positions 3
Action Spring Return from Right
Operating Cycles 1000000
Standard CCC,CSA,CUL,KC,MARINE,UL
