Allen-Bradley 800T-FXN1A7 30 mm Push-Pull Device for Push Button
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Usually ships within 11 to 17 Days
Already a Customer? Log in to view your pricing
Manufacturer Allen-Bradley / Rockwell
Mfg Catalog # 800T-FXN1A7
North Coast Part # 70583



  • Factory or User Assembled?: Factory Assembled

Push Button Data

  • Finger Safe Guards: No Guards
  • Head Type: Standard Size Plastic Mushroom Head (40mm)
  • Operator Function: OUT - Momentary / CENTER - Maintained / IN - Momentary
  • Cap/Button Color: Green
  • Block Type, First Level: Standard
  • Contact Blocks: 1 N.C.L.B. - 1 N.C. Op/Cntc: OUT-X IN-O, OUT-X IN-O


  • Note: Not a standard contact block configuration. Please Contact RA sales office.


GTiN 00781180621833
Color Green Lens
Type 30mm Push-Pull Device
Conductor Size 18-14 AWG
Mounting Type Screw
Operator Type Standard Mushroom Head
Temperature Rating -40 to 131 F
Family Brand Name Allen Bradley
Lamp Type LED
Enclosure Type NEMA 1, 4, 12, 13
Actuator 3-Position Momentary In
Contact Configuration 1 NCLB, 1 NC
Blade Dimensions 2-1/8 in L x 1-39/64 in W x 2-13/32 in H
Head Type Standard Size Plastic Mushroom Head (40mm)
Environmental Conditions 50 - 95% Relative Humidity
Bezel Material Metal
Lamp Voltage 600 VAC
Contact Rating 24 mA at 24 V Minimum, 10 A AC, 2.5 A DC Maximum
Action No Twist Release, Maintained
Operating Cycles 250000
Sub Brand 800T PB
Product UPC 78118062183
