Allen-Bradley 800T-H3205A 30.5 mm Type 4/13 2-Position Maintained 1 NO - 1 NC Cylinder Lock Selector Switch
Product image thumbnail 0
Product image thumbnail 1
$198.80/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer AB-PBS
Mfg Catalog # 800T-H3205A
North Coast Part # 998736

Specifications

  • Hazardous Location: No
  • Block Type: Standard

Assmebly

  • Factory or User Assembled?: Factory Assembled

Selector Switch Data

  • Finger Safe Guards: No Guards
  • Key Removal Position: Maintained, Lock - Right, Std. Key
  • Key Options: D335
  • Cam Option: Standard Cam
  • Block Type, First Level: Standard
  • Contact Blocks: 1 N.O. - 1 N.C.

Overview

UPC 66207389543
GTiN 00662073895435
Size 30.5 mm
Color Black, White
Type 30mm Selector Switch
Terminal Type Screw
Conductor Size 18-14 AWG
Mounting Type Hole
Temperature Rating -40 to 131 F
Family Brand Name Allen Bradley
Lamp Type LED
Actuator 2 Position Selector Switch
Contact Configuration 1 NO, 1 NC
Environmental Conditions 50 - 95% Relative Humidity
Bezel Material Metal
Number of Positions 2
Block Type Standard
Action Maintained, Key Removal From Right
Operating Cycles 1000000
Sub Brand 800T PB
Voltage 600 VAC
