Allen-Bradley 802B-CSDD1BSLD4 Compact Limit Switch
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Usually ships within 11 to 17 Days
Already a Customer? Log in to view your pricing
Manufacturer AB-SEN
Mfg Catalog # 802B-CSDD1BSLD4
North Coast Part # 1612899


  • Rugged die-cast housing
  • Industry standard dimensions
  • Compact size


Limit Switch Data

  • Switch Type: Compact
  • Head Configuration: Top Push Cross Roller, Booted
  • Mounting Style: Side Mount
  • Output Type: Low Voltage/Current
  • LED Indicator: Yes
  • Torque to Operate Contacts (Max.): 17.65N (3.97lb)
  • Travel to Operate Contacts (Nominal): 1.8mm (0.071in)
  • Maximum Travel: 5mm (0.197in)
  • Travel to Reset Contacts (Max.): 0.2mm (0.008in)
  • Connection Type: 4-pin DC Micro QD


UPC 61132076111
Item Long Description 802B Compact Compact Limit Switch
GTiN 00611320761115
Size 802B Compact
Operating Temperature -10 C
Type Compact
Applications Full Switch (Head and Body)
Mounting Type Side
Connection Type 4-pin DC Micro QD
Family Brand Name Allen Bradley
TC Connection 4 Pin, DC Micro
Actuator Booted Top Push Cross Roller
Contact Configuration 1 Circuit
Contact Rating B300
Number of Poles 2 Pole
Enclosure Metal
Standard KC
Material Metal
Temperature Rating -10 to 70 C
Number of Circuits 1
