A-B 802M-ASJ1 Factory Sealed Limit
Product image thumbnail 0
Product image thumbnail 1
$553.11/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer AB-SEN
Mfg Catalog # 802M-ASJ1
North Coast Part # 1009612

Specifications

Pre-Wired Factory Sealed Data

  • Switch Components: Complete Switch
  • Actuation Type: Lever Type, Spring Return, Sequential
  • Number of Circuits: 4-Circuit
  • Mode of Operation: CW and CCW operation
  • Travel to Operate Contacts (Max.): 10°+/- 3° (Position One)
  • Torque to Operate Contacts (Max.): 0.79N.m (7lb in) (Position 1)
  • Travel to Reset Contacts (Max.): 4° +/- 3°
  • Maximum Travel: 88°

Modifications

  • 24V DC Switch: Not 24V DC Model
  • Indicating Lights: No Indicating Light(s)
  • Connection Options: 9-Pin Mini-Type Receptacle

Operating Lever Data

  • Operating Lever: Operating Lever Not Selected

Overview

UPC 66207329136
GTiN 00662073291367
Type Factory Sealed Limit Switch
Connector Type 9 Pin Mini Type (J1 Wiring)
Family Brand Name Allen Bradley
TC Connection Mini Quick Disconnect
Actuator Lvr Type, Sprg Rtn, Sequential
Number of Poles 4 Pole
Connection Type 9 Pin Mini Type (J1 Wiring),Mini Quick Disconnect
