Allen-Bradley 802T-HTPE Metal Plug-In Oiltigh
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Usually ships within 11 to 17 Days
Already a Customer? Log in to view your pricing
Manufacturer AB-SEN
Mfg Catalog # 802T-HTPE
North Coast Part # 486536


Switch Data

  • Energy Rating: Standard Energy
  • Plug-In or NonPlug-In Style: Plug-In
  • Switch Components: Complete Switch
  • Actuation Type: Lever Type, Spring Return, High Operating Torque
  • Number of Circuits: 4-Circuit
  • Mode of Operation: CW and CCW operation
  • Safety Switch: No
  • Travel to Operate Contacts (Nominal): 9°
  • Torque to Operate Contacts (Max.): 0.79N-m (7lb in)
  • Travel to Reset Contacts (Max.): 3.5°
  • Maximum Travel: 90°


  • Low Temperature: Low Temperature

Operating Lever Data

  • Operating Lever: Operating Lever Not Selected


UPC 66246808304
Item Long Description Metal Plug-In Oiltight Limit Switch
GTiN 00662468083041
Size 802T Plug-in Style
Operating Temperature -40 C
Type Plug-In Oiltight Limit Switch
Applications Full Switch (Head & Body)
Family Brand Name Allen Bradley
TC Connection Cable Length Not Applicable,Number of Pins Not Applicable,Conduit Entry,Connector Type Not Applicable
Actuator Rotary Lever Arm
Contact Configuration 4 Circuits
Contact Rating A300
Number of Poles 2 Pole
Enclosure Metal
Mounting Type NEMA Style Standard Mounting
Standard KC
Connection Type Cable Length Not Applicable,Number Of Pins Not Applicable,Conduit Entry,Connector Type Not Applicable
