SATCO S29911 25T5/LED/46-850/DR
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$18.62/ea
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Satco
Mfg Catalog # S29911
North Coast Part # 1492516

Specifications

Case Packaging

  • Case UPC: 10045923299114
  • Case Quantity: 10
  • Case Length: 48.4
  • Case Width: 6.3
  • Case Height: 3.54
  • Case Weight: 5.13
  • Case Cube: 0.61

Individual Packaging

  • Each UPC: 045923299117
  • Each Quantity: 1
  • Each Length: 47.6
  • Each Width: 0.59
  • Each Height: 0.59
  • Each Weight: 0.1
  • Each Cube: 0.01

Product Details

  • Status: Active
  • Lamp Code: 25T5/LED/46-850/DR
  • Type: Lamps
  • Watts: 25
  • Fluorescent Equivalent: 54
  • Lamp Type: T5
  • Lamp Base: Miniature Bi Pin
  • Lamp Appearance: Gloss
  • Hours Rated: 50000
  • Lumens: 3500
  • Temperature: 5000
  • Color Temperature: Natural Light
  • CRI: 82
  • Beam Spread: 185
  • MOL: 48
  • MOD: 0.63
  • Nominal Length: 48
  • Pack Type: Sleeve
  • Tariff Code: 8539.50.0050
  • Unspsc: 39101628
  • Warranty: 5 Year Limited - T5 LED Bulbs
  • Brand: Satco
  • Country of Origin: China
  • CEC: Exempt - Base Not Regulated
  • CEC Terse: Lawful for sale in California
  • Dimmable: Non-Dimmable
  • DLC Approved: Yes
  • DLC ID: PL2M6895FL33
  • DLC Classification: Standard
  • Energy Star: No
  • NSF Approved: Yes - Approved
  • Operating Temperature: -20C (-4F) to a maximum of +45C (+113F)
  • Replaces: S9911
  • Safety Listing: cULus
  • Location Rating: Damp
  • Ballasting Requirements: Ballast required
  • Lamp Ballast Type (A/B/C): Type A
  • Includes: Integrated thermal fuse at pins
  • Power Factor: 0.9
  • ROHS Compliant: Yes
  • SDS Class: LED_Lamp
  • Technology: LED

Overview

UPC 04592329911
Item Long Description 25W T5 LED; Miniature bi-pin base; 5000K; 50000 Average rated hours; 3500 Lumens; Type A; Ballast dependent
GTiN 00045923299117
Warranty Length 5 yr
Size MOL: 48, MOD: 0.63 IN
Color Gloss
Type Lamps
Country of Origin China
Wattage 25 Watt
Color Temperature 5000 K
Lumens 3500 lm
Base Miniature Bi Pin
Pkg Qty 10
Shape T5
Family Brand Name Satco Products
Lamp Type T5
Dimmable? No
Fixture Type Fluorescent Replacement
Beam Spread 185 degrees
TC Connection Miniature Bi Pin
Correlated Color Temp Natural Light K
Color Rendering Index 82 CRI
Sub Brand Satco
Voltage 120 Volt
