SATCO S8691 13T5/LED/46-840/BP/HE/1
$20.64/ea
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Satco
Mfg Catalog # S8691
North Coast Part # 1492542

Specifications

Case Packaging

  • Case UPC: 10045923086912
  • Case Quantity: 25
  • Case Length: 48.1
  • Case Width: 5.2
  • Case Height: 5.2
  • Case Weight: 12.9
  • Case Cube: 0.73

Individual Packaging

  • Each UPC: 045923086915
  • Each Quantity: 1
  • Each Length: 45.8
  • Each Width: 0.8
  • Each Height: 0.8
  • Each Weight: 0.4
  • Each Cube: 0.02

Product Details

  • Status: Active
  • Lamp Code: 13T5/LED/46-840/BP/HE/120-277V
  • Type: Lamps
  • Volts: 120V-277V
  • Watts: 13
  • Lamp Type: T5
  • Lamp Base: Miniature Bi Pin
  • Lamp Appearance: Frosted
  • Housing Color: Silver
  • Hours Rated: 50000
  • Lumens: 1650
  • Temperature: 4000
  • Color Temperature: Cool White
  • CRI: 83
  • Beam Spread: 240
  • MOL: 48
  • MOD: 0.88
  • Nominal Length: 48
  • Pack Type: Sleeve
  • Tariff Code: 8539.50.0050
  • Unspsc: 39101628
  • Warranty: 5 Year Limited - T5 LED Bulbs - Ballast Bypass
  • Brand: Satco
  • Country of Origin: China
  • CEC: Exempt - Base Not Regulated
  • CEC Terse: Lawful for sale in California
  • Dimmable: Non-Dimmable
  • DLC Approved: Yes
  • DLC ID: PLJKLU33P9OA
  • DLC Classification: Standard
  • Energy Star: No
  • NSF Approved: Yes - Approved
  • Safety Listing: cULus Classified
  • Location Rating: Damp
  • Ballasting Requirements: Ballast Bypass
  • Lamp Ballast Type (A/B/C): Type B
  • Power Factor: 0.91
  • ROHS Compliant: Yes
  • SDS Class: LED_Lamp
  • Technology: LED

Overview

UPC 04592308691
GTiN 00045923086915
Warranty Length 5 yr
Size MOL: 48, MOD: 0.88 IN
Color Silver
Voltage 120-277 Volt
Type Lamps
Country of Origin China
Wattage 13 Watt
Color Temperature 4000 K
Lumens 1650 lm
Base Miniature Bi Pin
Pkg Qty 25
Shape T5
Family Brand Name Satco Products
Lamp Type T5
Dimmable? No
Fixture Type LED T5
Beam Spread 240 degrees
TC Connection Miniature Bi Pin
Correlated Color Temp Cool White K
Color Rendering Index 83 CRI
Sub Brand Satco
