SATCO S8786 16A21/LED/30K/ND/120V
Product image thumbnail 0
Product image thumbnail 1
$13.58/ea
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Satco
Mfg Catalog # S8786
North Coast Part # 1428000

Specifications

Case Packaging

  • Case UPC: 10045923087865
  • Case Quantity: 24
  • Case Length In.: 15.55
  • Case Width In.: 10.39
  • Case Height In.: 14.41
  • Case Weight Lb.: 9.22
  • Case Cubic In.: 1.3473

Individual Packaging

  • Each UPC: 045923087868
  • Each Quantity: 1
  • Each Length In.: 3.46
  • Each Width In.: 3.07
  • Each Height In.: 6.3
  • Each Weight Lb.: 0.32
  • Each Cubic In.: 0.0387

Product Details

  • Status: Transitioning
  • Substitute: S28786
  • Lamp Code: 16A21/LED/30K/ND/120V
  • Type: Lamps
  • Volts: 120V
  • Watts: 16
  • Incandescent Equiv: 100
  • Lamp Type: A21
  • Lamp Base: Medium
  • ANSI Base: E26
  • Lamp Appearance: Frosted
  • Housing Color: White
  • Avg Rated Hours: 15000
  • Lumens: 1600
  • Temperature: 3000
  • Color Temp: Warm White
  • CRI: 80
  • Beam Spread: 220
  • MOL Fraction In.: 5 1/2
  • MOL Decimal In.: 5.5
  • MOD Fraction In.: 2 5/8
  • MOD Decimal In.: 2.63
  • Weight Lb.: 0.37
  • Pack Type: Box
  • Inner UPC: 20045923087862
  • Inner Quantity: 6
  • Inner Length In.: 9.72
  • Inner Width In.: 7.32
  • Inner Height In.: 6.65
  • Inner Weight Lb.: 2.16
  • Inner Cubic In.: 0.2738
  • Tariff Code: 8539.50.0090
  • UNSPSC: 39101628
  • Warranty: 3 Year Limited
  • Brand: Satco
  • Country of Origin: China
  • CEC: Non-Compliant - Not 82 CRI
  • CEC Alt Sub: S8653; S8567
  • CEC Terse: Non-Compliant
  • Dimmable: Non-Dimmable
  • Enclosure Rating: Enclosed Rated Lamp
  • ENERGY STAR Text: No
  • Operating Temp: -20C (-4F) to a maximum of +45C (+113F)
  • Safety Listing: cULus - Damp
  • Power Factor: 0.94
  • RoHS Compliant: Yes
  • SDS Class: LED_Lamp
  • Technology: LED

Overview

UPC 04592308786
GTiN 00045923087868
Warranty Length 3 yr
Size MOL: 5.5, MOD: 2.63 IN
Color Frost
Voltage 120 Volt
Type Lamps
Country of Origin China
Wattage 16 Watt
Lumens 1600 lm
Base Medium
Pkg Qty 24
Shape A21
Family Brand Name Satco Products
Lamp Type A21
Dimmable? No
ANSI Base E26
Fixture Type Decorative Fixtures
Beam Spread 220 degrees
TC Connection Medium
Correlated Color Temp Warm White
Average Rated Life 15000 hr
Color Rendering Index 80 CRI
Sub Brand Satco

Substitutes (1)
