S-A 3RV27111HD10 TMCB UL489 S00 8A
Product image thumbnail 0
Product image thumbnail 1
$346.17/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Siemens
Mfg Catalog # 3RV27111HD10
North Coast Part # 1498658

Specifications

  • Pole number: 3
  • Protection type IP: IP20 /
  • Motor drive optional: false
  • Integrated motor drive: false
  • Connection type: Screw connection
  • under voltage release present: false
  • Rated permanent current Iu: 8.0 ampere
  • tripped signaling device present: false
  • Number of auxiliary contacts as opener: 0
  • Number of auxiliary contacts as changer: 0
  • Number of auxiliary contacts as shutter: 0
  • Device type: Einbaugerät Festeinbautechnik
  • integrated earth-fault protection present: false
  • suitable for mounting onto standard rails: false
  • Power loss per pole, current-dependent [PlIp]: 3.1 watt
  • Rated current [In] for the power loss specification: 8.0 ampere

Overview

UPC 66264392282
GTiN 00662643922820
Length 7.520 in
Width 2.170 in
Operating Temperature -20 C
Voltage 690 Volt
Type 3RV2 circuit breaker
Applications For system protection
Height 4.340 in
Country of Origin Germany
Connection Type Screw Connection
Family Brand Name Siemens
TC Connection screw-type terminals
Actuator selector switch
Environmental Conditions 80 to 50 C
Number of Poles 3 Pole
Sub Brand SIRIUS
