Siemens Industry 3SE52320PC05 M20 x 1.5 Plastic 2NO 1NC Slow Action Twist Lever Limit Switch
Usually ships within 6 to 8 Days
Already a Customer? Log in to view your pricing
Manufacturer Siemens
Mfg Catalog # 3SE52320PC05
North Coast Part # 760805


  • Number of safety auxiliary contacts: 1
  • Rated operation current Ie at AC-15, 24 V: 6 A
  • Rated operation current Ie at DC-13, 24 V: 3 A
  • Number of contacts as normally closed contact: 1
  • Number of contacts as normally open contact: 2
  • Number of contacts as change-over contact: 0
  • Ambient temperature during operating: 85 °C
  • Ambient temperature during operating: -25 °C
  • Suitable for safety functions: true
  • Forced opening: true
  • Rated operation current Ie at DC-13, 125 V: 0.55 A
  • Width sensor: 31.0 mm
  • Height of sensor: 33.0 mm
  • Length of sensor: 75.7 mm
  • With status indication: false
  • Output electronic: false
  • Switching function latching: false
  • Switching function: Slow-action switch
  • Material housing: Plastic
  • Coating housing: Other
  • Type of interface for safety communication: None
  • Type of electric connection: Cable entry metrical
  • Explosion safety category for gas: None
  • Explosion safety category for dust: None
  • Construction type housing: Cuboid
  • Degree of protection (IP): IP65
  • Type of control element: Plunger
  • Type of interface: None
  • Alignment of the control element: Roller cam straight


UPC 66264385114
GTiN 00662643851144
Length 1.660 in
Width 1.780 in
Height 3.820 in
Country of Origin Germany
Connection Type Cable Entry Metrical
Family Brand Name Siemens
Housing Material Plastic
