S-A 52BT6G3A PTT PL/ILL PB,GRN,XFMR
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$175.45/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Siemens
Mfg Catalog # 52BT6G3A
North Coast Part # 886107

Specifications

  • Height: 1.000 IN
  • Width: 2.000 IN
  • Length: 1.000 IN
  • Gross Weight per Pack: 0.070 Lbs
  • Packaging Description: Piece
  • Country of Origin: MX
  • ROHS Indicator: DQ

Categories

Overview

UPC 66264331424
Item Long Description 30mm blackmax, epoxy coated corrosion resistant complete metal unit ptt / illuminated pushbutton transformer type, 120V AC incandescent lamp extended button plastic lens, green 2 position momentary with 1 n.o. - 1 n.c. heavy duty contacts, a600/p600 ul listed, csa certified NEMA 1, 3, 3r, 4, 4x, 12, 13 & automotive standards
GTiN 00662643314243
Length 1.000 in
Width 2.000 in
Size 30 mm Pilot Device
Operating Temperature -31 To 158 F
Voltage 600 Volt
Type Illuminated
Applications Use with magnetic controllers to control the starting, and stopping of motors. Open type devices are designed for mounting in sheet metal enclosures or for mounting on flush plates.
Height 1.000 in
Country of Origin Mexico
Family Brand Name Siemens
Actuator Pushbutton
Contact Configuration 1NO-1NC
Amperage 10 Amp
Contact Rating A600 / P600
Action DP
Operating Cycles 300k
Sub Brand BlackMax
