S-A BQ2B045QXD BRKR BQXD 2P 120/240
Product image thumbnail 0
Product image thumbnail 1
Usually ships within 6 to 10 Days
Already a Customer? Log in to view your pricing
Manufacturer Siemens
Mfg Catalog # BQ2B045QXD
North Coast Part # 1019148


  • Continuous current rated value: 45 A
  • Voltage between phase and Ground (GND) rated value: 120 V
  • Voltage between phase and phase rated value: 240 V
  • Supply voltage frequency rated value 50/60 Hz: TRUE
  • Suitability for operation: ELECTRICAL DISTRIBUTION
  • Number of poles: 2
  • Mounting type: DIN RAIL
  • Design of the product: BQXD
  • Size of the circuit-breaker: BQ (125A)
  • Design of the overload release: THERMAL - MAGNETIC
  • Height [in]: 4.5 in
  • Width [in]: 2 in
  • Depth [in]: 3 in
  • Product feature: 10kA INTERRUPT
  • Type of electrical connection: MECHANICAL LUGS
  • Product brand name: SIEMENS
  • Type of mounting panel: OEM PANELS
  • Type of connectable conductor cross-sections at AWG conductors for supply single or multi-stranded: 8 - 1AWG (CU) / 6 - 1/0AWG (AL)


UPC 78364316975
Item Long Description Siemens Low Voltage Molded Case Circuit Breakers General Purpose MCCBs are Circuit Protection Molded Case Circuit Breakers. 2-Pole Common-Trip circuit breaker type BQXD. Rated 120/240V (045A) (AIR 10 kA). Special features DIN Rail mounted,Connectors line side (Lugs), load side (Quick-Connect)..
GTiN 00783643169753
Length 6 in
Width 2 in
Voltage 120/240 Volt
Applications Electrical Distribution
Mounting Type DIN RAIL
Depth 3 in
Height 4.5 in
Connection Type Bolt-On
Family Brand Name Siemens
TC Connection BOLT-ON
Number of Poles 2 Pole
Interrupt Rating 10 A
Trip Range Thermal Magnetic
Operating Temperature N/A
Frame N/A
Actuator N/A
Trip Type N/A
Load Rating N/A
Enclosure N/A
Sub Brand N/A
