S-A HQN2150R BREAKER 150A 2P 120/24
Product image thumbnail 0
Product image thumbnail 1
$1,163.53/ea
Usually ships within 6 to 10 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Siemens
Mfg Catalog # HQN2150R
North Coast Part # 1347136

Specifications

  • Design of the product: HQNR
  • Type of electrical connection: PLUG-IN
  • Standard: UL 489
  • Suitability for operation: Electrical Distribution
  • Product brandname: SIEMENS
  • Design of the overload release: Thermal Magnetic
  • Number of poles: 2
  • Voltage between phase and Ground (GND) rated value: 120 V
  • Voltage between phase and phase rated value: 240 V
  • Height [in]: 3 in
  • Depth [in]: 9 in
  • Width [in]: 6 in
  • Continuous current rated value: 50 A

Overview

UPC 78364334110
Item Long Description Siemens Low Voltage Residential Circuit Breakers Main Breakers - Branch Main Breaker Reversible are Circuit Protection Load Center Mains, Feeders, and Miniature Circuit Breakers. Type HQNR Application Electrical Distribution Standard UL 489 Voltage Rating 120/240V Amperage Rating 50A Trip Range Thermal Magnetic Interrupt Rating 65 AIC Number Of Poles 2P
GTiN 00783643341104
Length 9 in
Width 6 in
Voltage 120/240 Volt
Type HQNR
Applications ElectricalDistribution
Depth 9 in
Height 3 in
Connection Type Plug-In
Family Brand Name Siemens
TC Connection PLUG-IN
Number of Poles 2 Pole
Interrupt Rating 65 A
Trip Range Thermal Magnetic
Operating Temperature N/A
Frame N/A
Actuator N/A
Trip Type ThermalMagnetic
Load Rating N/A
Enclosure N/A
Sub Brand N/A
