Siemens Ca JD62B300 JD MCCB,25kA@60
$1,739.09/ea
Usually ships within 6 to 10 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Siemens
Mfg Catalog # JD62B300
North Coast Part # 606103
SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETICTRIP UNIT. UN-ASSEMBLED STANDARD 40 DEG C BREAKER JD FRAME WITH STANDARD BREAKING CAPACITY. 300A 2-POLE (25KAIC AT 600V) (35KAIC AT 480V). INTERCHANGEABLE TRIPUNIT. SPECIAL FEATURES LINE AND LOAD SIDE LUGS (TA2J6500) WIRE RANGE 3/0AWG - 500KCMIL (CU) / 4/0AWG - 500KCMIL (AL). DIMENSIONS (W x H x D) IN 7.50 x 11.0 x 4.00.

Overview

UPC 78364321313
GTiN 00783643213135
Length 7.000
Width 9.000
Operating Temperature 40 C
Voltage 600 Volt
Type JD6
Applications Standard 40C Breaker
Height 13 in
Standard HACR
Frequency 50/60 Hz
Family Brand Name Siemens
Frame JD
Actuator Varying
Amperage 300 Amp
Trip Type Thermal-Magnetic
Number of Poles 2 Pole
Interrupt Rating 25 kA
Enclosure Varying
Trip Range 1250-2500
Sub Brand Sentron
TC Connection N/A
Load Rating N/A
