$932.35/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Siemens
Mfg Catalog # QR23B100L
North Coast Part # 1829780

Specifications

  • Standard: UL489 / CSA-C22.2 / NOM-003
  • Continuous current rated value: 100 A
  • Voltage between phase and phase rated value: 240 V
  • Supply voltage frequency rated value 50/60 Hz: TRUE
  • Suitability for operation: ELECTRICAL DISTRIBUTION
  • Number of poles: 3 0
  • Design of the product: QR2
  • Size of the circuit-breaker: QR (250A)
  • Design of the overload release: THERMAL - MAGNETIC
  • Height [in]: 7 in
  • Width [in]: 4.5 in
  • Depth [in]: 3.39 in
  • Product feature: 10kAIC INTERRUPT
  • Type of electrical connection: MECHANICAL LUGS
  • Product brandname: SIEMENS
  • Type of connectable conductor cross-sections at AWG conductors for load-side outgoing feeder single or multi-stranded: 2/0AWG - 300KCMIL (CU/AL)
  • Type of mounting panel: CONTROL AND DISTRIBUTION BOARDS
  • Type of connectable conductor cross-sections at AWG conductors for line-side single or multi-stranded: 2/0AWG - 300KCMIL (CU/AL)

Overview

UPC 80476613669
GTiN 00804766136696
Width 4.5 in
Operating Temperature 40DEGC
Type Cable In - Cable Out 240V Circuit Breakers
Applications Circuit Protection
Depth 3.39 in
Height 7 in
Family Brand Name Siemens
TC Connection Line and Load Lugs
Trip Type Thermal Magnetic
Number of Poles 30 Pole
Interrupt Rating 10kA
Sub Brand QR
Voltage null
