MR 1SHP SET SCREW SMALL No18-No12
Product image thumbnail 0
Product image thumbnail 1
$2,496.41/m (1000 ea)
Usually ships within 9 to 15 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Thomas & Betts
Mfg Catalog # 1SHP
North Coast Part # 1014989

Features

  • External cap made of rugged, phenolic material and 150 degree C rated.
  • Choice of slot or Robertson set screw.
  • No need to in.re-strip in. wires when re-wiring. Simply loosen set screw to remove non-twisted wires.

Specifications

North American Specifications (UNSPSC)

  • UNSPSC: 39121409 Wire connectors
  • IGCC: 4543 Wire connectors
  • Brand Name: Marrette
  • Type: Two-Piece Connectors
  • Special Features: External cap made of rugged, phenolic material and 150 degree C rated.
  • Standard: UL E9809
  • Wire Size: 18-12
  • Color: Black
  • Voltage Rating: Approved for circuits up to 600 V, and lighting fixtures and signs up to 1000 V
  • Wire Type: Copper Conductor Only

Packaging

  • Inner Quantity: 100
  • Inner Dimensions (inches): 2.75x3x5
  • Outer Quantity: 1000
  • Outer Dimensions (inches): 0x0x500
  • Weight Uom: 1 lbs. per 100

Overview

UPC 06739600876
Item Long Description Small Set Screw, Phenolic Material, Robertson, Wire Range #18-12 AWG, Temperature Rated 150 Degrees C, Black
GTiN 05415022224238
Color Black
Type Small Set Screw
Material Phenolic
Conductor Size 18-12 AWG
Wire Size 18-12 AWG
Wire Type Copper Conductor Only
Temperature Rating 150 C
Family Brand Name Marrette
Used With Circuits upto 600 V and Lighting Fixtures and Signs upto 1000 V
Sub Brand Marrette
Voltage 1000 Volt
Standard UL E9809
Box Quantity 1000
