Ty-Fast TY400-50 60.6 Inch 50 lb Natural Nylon Cable Tie
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$43.81/c (100 ea)
Usually ships within 11 to 17 Days
ea
Adding...
Order in multiples of 1000 (pack qty) Already a Customer? Log in to view your pricing
Manufacturer Thomas & Betts / Catamount
Mfg Catalog # TY400-50
North Coast Part # 156236

Features

  • The integrally formed nylon pawl combines low insertion and high locking strength.
  • Application Tools: ERG50, QC-100, L-200, L-400-C

Specifications

North American Specifications (UNSPSC)

  • UNSPSC: 39121703 Cable ties
  • IGCC: 5034 Cable ties
  • Brand Name: Ty-Fast
  • Type: Standard
  • Special Features: The integrally formed nylon pawl combines low insertion and high locking strength.
  • Standard: UL E49405
  • Width: 0.184 in ; 4.674 mm
  • Length: 14.4 in ; 365.76 mm
  • Thickness: 0.049 Inch/1.24mm
  • Bundle Diameter: 0.06 Inches/1.6mm-4.02 Inches/102mm
  • Material: Nylon/Polyamide 6.6
  • Color: Natural
  • Lock Mechanism: Plastic Pawl
  • Tensile Strength: 50 Pounds/220 Newtons

European Specifications (ETIM)

  • ETIM: EC000046 Cable tie
  • Band width: 4.673mm
  • Length belt/tape/tie: 365.76mm
  • Tie thickness: 1.24mm
  • Max. bundle diameter: 101.6mm
  • Min. holding force: 220N
  • Operating temperature: -40-+85°C
  • Model: Internal toothing
  • Band closure: Plastic lip/-cam
  • Material: Plastic
  • Material quality: Polyamide PA
  • Surface protection: Untreated
  • Halogen free: Y
  • Colour: Natural colour
  • Transparent: N
  • Reflective (fluorescent): N
  • Text strip: None
  • Solvable fastener: N
  • MIL approval: N
  • UL approval: Y

Packaging

  • Inner Quantity: 1000
  • Inner Dimensions (inches): 21x15x4
  • Outer Quantity: 5000
  • Outer Dimensions (inches): 18.7x13.95x13.5
  • Weight Uom: 5 lbs. per 1000

Categories

Overview

UPC 78621089854
Item Long Description Cable Tie, Natural Polyamide (Nylon 6.6) for Temperatures up to 85 Degrees Celsius (185 F) for Indoor Applications, UL/EN/CSA62275 Type 2/21S Rated for AH-2 Plenum and as a Flexible Cable and Conduit Support, Length of 365.76mm (14.4 Inches), Width of 4.674mm (0.184 Inch), Thickness of 1.24mm (0.049 Inch), Tensile Strength Rating of 220 Newtons (50 Pounds), Bulk Pack
GTiN 00786210898544
Length 14.4 in
Width 0.184 in
Color Natural
Operating Temperature -40 To 85 C
Type General Purpose
Thickness 0.049 in
Material Nylon,Plastic,Polyamide,Polyamide PA
Family Brand Name Thomas & Betts
Box Quantity 5000
Tensile Strength 50 pounds ; 220 newtons
Bundle Diameter 0.06 to 4.02 in ; 1.6 to 102 mm
