TB SLND-M160 CONDUIT FTNG STR M16 N
$168.76/c (100 ea)
Usually ships within 9 to 15 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Thomas & Betts
Mfg Catalog # SLND-M160
North Coast Part # 827954

Features

  • Easy push-in installation
  • Easy re-opening with screwdriver
  • Space savings due to compact design
  • Self-extinguishing, free of halogens and cadmium
  • Excellent impact strength
  • Fits both conduit profiles - fine (T) and coarse (G)

Specifications

North American Specifications (UNSPSC)

  • UNSPSC: 39121420 Liquid tight connectors
  • IGCC: 4585 Liquid tight connectors
  • Brand Name: PMA
  • Type: Connectors-Straight
  • Size: NW10
  • Connection: M16x1.5
  • Material: Polyamide 6
  • Color: Gray

European Specifications (ETIM)

  • ETIM: EC001176 Screw connection for corrugated plastic hose
  • Nominal diameter: 12mm
  • Degree of protection (IP): IP66
  • Model: Straight
  • Revolving thread: N
  • Construction type: Internal thread
  • Type of connection: Snap connection
  • Thread type: Metric
  • Thread connection size: M16 x 1.5
  • Thread material: Polyamide
  • Thread length: 11mm
  • Total length: 34mm
  • Material: Polyamide
  • Material sealing: No sealing
  • Colour: Grey
  • Approved in combination with protective conduit CSA: N
  • Approved in combination with protective conduit UR: N
  • Approved in combination with protective conduit DIN EN 61386-23: N
  • Approved in combination with protective conduit Lloyd's Register: N
  • Operating temperature: -45 - +105°C

Packaging

  • Inner Quantity: 100
  • Outer Quantity: 1000
  • Outer Dimensions (inches): 15.748x11.811x8.661
  • Weight Uom: 0.01 lbs. Each

Overview

UPC 78620997091
GTiN 00786209970916
Color Gray
Operating Temperature -45 To 105 C
Diameter 12 mm
Material Nylon 6
Construction Type Internal Thread
Connection Type M16x1.5
Thread Length 11 mm
Family Brand Name Thomas & Betts
Carton Qty 100
Box Quantity 1000
IP Rating IP66
Thread Type Metric
Size NW10 ; M16x1.5 Thread
Type Connectors-Straight
TC Connection M16x1.5
